Overview:
The digital conductivity sensor adopts a new generation of four-electrode/six-electrode technology, with a wide measurement range and automatic range switching. Automatic temperature compensation for the changing temperature of the water body. It has excellent anti-pollution ability and will not cause polarization even in harsh environments for long-term online monitoring. An RS458 output can be networked without a controller.
Features of DS480 Water Conductivity Sensor:
- Small in size, it can be assembled in many ways.
- Wide measurement range, automatic switching of measurement ranges.
- Built-in temperature sensor, automatic temperature compensation.
- four/six electrode technology, no polarization.
- Digital Sensor, RS458 output, support Modbus.
Technical parameter:
| Product Name | DS480 Conductivity Sensor |
|---|---|
| Range | 1uS/cm-300 mS/cm |
| Accuracy | 3% |
| Resolution | 1uS/cm |
| Principle | Electrode method |
| Temperature range | 0~ 50°C |
| Storage temperature | -20~ 80°C |
| Output signal | RS-485 、 MODBUS protocol |
| Calibration method | 1 or 2 point calibration |
| Waterproof level | IP68 |
| Max pressure | 3bar |
| Housing material | 316/POM |
| Dimensions | Φ22 X 152.5mm |
| Power information | DC 6~12V，Current<50mA |
| Cable length | Standard 5 meters |
| Response Time | ＜2 sec |
